75mm-250mm HDPE Pipe Production Line 410kg/H PE Pipe Extrusion Machine

Name: 75mm250mm HDPE Pipe Production Line 410kgH PE Pipe Extrusion Machine
Brand: Changyue
Price: 1 USD

Quality 75mm-250mm HDPE Pipe Production Line 410kg/H PE Pipe Extrusion Machine for sale

Certification : ISO9001

Model NO. : SJ 75 / 33

Feeding Mode : One Feed

Assembly Structure : Separate Type Extruder

Screw : Single-Screw

Engagement System : Full Intermeshing

Screw Channel Structure : Deep Screw

Exhaust : Exhaust

Automation : Automatic

Computerized : Computerized

Pipe Size 1 : 20-110 mm

Pipe Size 2 : 50-160 mm

Pipe Size 3 : 75-250 mm

Pipe Size 4 : 90-315 mm

Pipe Size 5 : 200-400 mm

Pipe Size 6 : 315-630 mm

Pipe Size 7 : 400-800 mm

Pipe Size 8 : 630-1000 mm

Pipe Size 9 : 710-1200 mm

Transport Package : Film

Specification : 20-63mm

Trademark : HYD

Origin : Shandong, China

HS Code : 84772090

Type : Pipe Extruder

Plastic Processed : PE

Product Type : Extrusion Molding Machine

Customization : Available | Customized Request

Shipping Cost : about shipping cost and estimated delivery time.

: Initial Payment Full Payment

Currency : US$

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

Place of Origin : Shandong, China

Brand Name : Changyue

Packaging Details : Export Film Packing / According To Customer

Delivery Time : 15 Days (1 - 1 Pieces) To Be Negotiated ( > 1 Pieces)

Contact Now

75-250 mm Full Intermeshing HDPE Water Supply Pipe Extrusion Production Line with Full

HDPE pipe production line

Prouduct description
PE pipe extrusion machine is mainly used for producing agricultural irrigation pipes,drainage pipes,gas pipes,water supplying pipes,cable conduit pipes etc. The pipe has some excellent features such as heating resistant,etc. our extrusion line is designed with high efficiency extruder and equipped with reducer which is high speed and low noise,Gravimetric dosing unit and ultrasonic thickness indicator can be assembled according to customer's demand to ascend the priecise of the pipes.Turn key solution can be provided, like laser printer , crusher,shredder, water chiller,air compressor etc. to achieve high-grade and automatic tube production.

Process Flow:
Raw material+master batches-Mixing-Vacuum feeder-Plastic hopper drier-Single screw extruder- Co-extruder for color string&multi layers-Mould-Vacuum calibration tank-Spray cooling water tank-Haul off-No dust cutter-double/single disc winding/stacker-Final product inspecting&packing

Technical parameter

pipe range(mm)	20-63	20-110	75-250	90-315	110-450	250-630	400-800
extruder model	SJ65/33	SJ65/33	SJ60/38	SJ75/38	SJ75/38	SJ90/38	SJ120/38
extruder power(kw)	45	75	110	160	160	280	315
max.output(kg/h)	130	220	410	580	580	900	1150

75mm-250mm HDPE Pipe Production Line 410kg/H PE Pipe Extrusion Machine

Our customer&exhibition

Packing
75mm-250mm HDPE Pipe Production Line 410kg/H PE Pipe Extrusion Machine
